The next important step is the setting of the aspect ratio of our figure, which will be 0.6:1. This latter one is empty, but we still need the space for it, so we set it to ' '. For the very same reason, we also unset the ytics, and set the y2tics. We do this, because the whole image will be rotated, and by rotating the xtics, we make sure that those will be horizontal at the end. For more on this, check out the gnuplot demo page! We then rotate the xtics by 90 degrees. The content of these lines might depend on what exactly we intend to plot. In the next four lines, we set up our histogram. You can see the exact syntax by issuing ?key in the gnuplot prompt. If you want smaller or larger space between the keys, you can modify this, by adding the spacing flag to the set command. We simply specify the coordinates and that that we want to have a horizontal key (i.e., one in which the keys are placed to the right of the previous one), with a length of 0.1. The first line after the reset is required, because we have to make our key ourselves. Set label 3 'Everywhere' at graph 0.2, 0.85 left rotate by 90 Set label 2 'Nowhere' at graph 0.09, 0.85 left rotate by 90
Set label 1 'Year' at graph 0.5, -0.1 centre rotate by 180
Set key at graph 0.24, 0.85 horizontal samplen 0.1 The figure above was produced based on the following data fileĪfter this interlude, let us see the code! I will discuss it afterwards. If you set the terminal to a raster format, or print the screen, you can rotate the image in many applications, but if you want to adhere to the command line, you can, at least, under Linux, use the convert command asĬonvert -rotate 90 figure_in.png figure_out.png If you set the terminal to postscript, you will probably use the figure in LaTeX, where you can simply tell the compiler to rotate the figure by 90 degrees. What we should note, however, is that we will still produce an upright image that we have to rotate later.
Making the graphs will require some work, but everything is quite straightforward.
Gnuplot set xtics how to#
If you want to learn how to produce the figure below, keep reading! For one thing, the horizontal one might take up much less space. But sometimes, this is not the best way to represent data, and a horizontal version would be much better. If you needed it in the past, you have probably realised that gnuplot can make only vertical histograms. Turning a histogram I have seen people searching for a solution to this problem with the histograms. First we will look into how the histogram can be made horizontal. But the problem of histograms is a bit broader than just making them shining. However, in the course of time, I came to realise that there are easier ways of getting the same results, therefore, here I will only show the simpler route. The method was a bit awkward, for it relied on an external gawk script, but if you are interested, you can still check out the details. At the early stages of writing my blog on various gnuplot-related tricks, I discussed a way of making histograms a bit more interesting.
